2026 Trek Fuel MX 9 XT Di2 Gen 7 Aluminium Trail Mountain Bike

0 reviews

USD 3,700.00

Brand: Trek

Product Code: TR903318WR

Availability: In Stock

Viewed 20 times

Available Options

Color:

Size

Qty

Add to wishlist
Add to compare

Tags: Trek Mountain Bike

Categories Cart Account Search Recent View

Product Description

2026 Trek Fuel MX 9 XT Di2 Gen 7 Aluminium Trail Mountain

The Fuel MX 9 XT Di2 is a playful trail bike made for hunting down side hits and chasing chaos. It features a robust Alpha NEXT Platinum aluminium frame paired with a top-tier Fox Factory suspension package (160mm front/150mm rear) and an MX (Mullet) wheel setup for a ride that is flickable and zippy. Shimano's wireless XT Di2 12-speed drivetrain delivers ultra-crisp, customizable shifting, while 4-piston XT M8200 brakes provide the modulation and stop-on-a-penny power needed when things get hairy.

Technical Specifications

Frame & Chassis
Frame Material	Alpha NEXT Platinum Aluminium
Frame Design	Gen 7, Internal Storage, Angle-adjust headset, Adjustable Leverage Rate, ABP, UDH, Boost148
Wheel Size	MX / Mullet (29" Front / 27.5" Rear)
Weight	16.96 kg / 37.4 lbs (Size M)
Suspension
Fork	Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 160 mm travel
Rear Shock	Fox Factory Float X, 2-position damper, 205 mm x 60 mm (150 mm travel)
Drivetrain (Wireless Electronic)
Rear Derailleur	Shimano XT M8250 Di2, long cage, 12-speed
Shifters	Shimano XT Di2 M8250, 12-speed wireless
Crankset	Shimano XT 8200, 30T, 170 mm length
Cassette	Shimano XT M8200, 10-51, 12-speed
Chain	Shimano XT M8100, 12-speed
Bottom Bracket	Shimano BB-MT501 BSA threaded
Brakes & Cockpit
Brakeset	Shimano XT M8200 4-piston hydraulic disc
Rotors	Shimano RT86, 6-bolt (203 mm Front / 180 mm Rear)
Handlebars	Race Face Turbine, alloy, 35 mm, 780 mm width, 40 mm rise
Stem	Bontrager Elite, 35 mm, 0-degree, 45 mm length
Seatpost	Bontrager Line Dropper, 34.9 mm (Travel: S:150mm, M:170mm, L/XL:200mm)
Saddle	Verse Short Comp, Steel Rails, 145 mm width
Wheels & Tires
Wheels	Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108
Front Tire	Maxxis Assegai, 3C MaxxGrip, EXO+, 29x2.5"
Rear Tire	Maxxis Minion DHR II, 3C MaxxTerra, EXO+, 27.5x2.5"

Key Features

MX "Mullet" Setup: Combines a 29" front wheel for rolling over obstacles with a 27.5" rear wheel for snappy cornering and extra backside clearance.
Alpha NEXT Platinum: Trek's highest-grade aluminium frame featuring progressive geometry and the versatile BITS internal downtube storage system.
Wireless XT Di2: Shimano’s latest electronic shifting technology provides lightning-fast gear changes and customizable settings via the E-Tube Project app.
Fox Factory Series: Gold-standard suspension with the GRIP X2 damper, providing elite tracking and mid-stroke support for aggressive trail riding.
Gen 7 Versatility: Outfitted with Mino Link and angle-adjust headset compatibility, allowing you to fine-tune the head angle and BB height.

Size Guide

Size	Rider Height (cm)	Rider Height (ft/in)	Inseam (cm)	Inseam (in)
S	155 - 165 cm	5'1" - 5'5"	74 - 78 cm	29" - 31"
M	165 - 176 cm	5'5" - 5'9"	79 - 83 cm	31" - 33"
L	177 - 188 cm	5'10" - 6'2"	84 - 89 cm	33" - 35"
XL	188 - 195 cm	6'2" - 6'5"	89 - 91 cm	35" - 36"
2XL	195 - 203 cm	6'5" - 6'8"	91 - 97 cm	36" - 38"
